Swing check valve - GG 25, DN 65, PN 16 - seat metal to metal, with counterweight

Swing check valve - GG 25, DN 65, PN 16 - seat metal to metal, with counterweight

Article number: J018110

Swing type check valve -GG-25 -seat metal to metal, with counterweight

T= -10°C up to max. 80°C, face to face acc. to EN 558-1 row 48, body/cover: GG-25, pin: stainless steel-X20Cr13, seat: brass, swing: GG-25, weight: GG-25

Data sheet J0181

Article overview

Article no J018108 J018109 J018110 J018111 J018112 J018113 J018114 J018115 J018116 J018117
Nominal pressure [bar] 16 16 16 16 16 16 16 16 16 16
Overall length [mm] 180 200 240 260 300 350 400 500 600 700
Weight [kg] 8 10 15 20 26 35 48 72 135 196
Show Show Show Show Show Show Show Show Show Show

Technical information

Product group
Swing check valves
Design
2-way
Connection method
Flange type
Material
GG-25
Nominal width / Thread
DN 65
Approval
Without approval
Weight
15000 g
Overall length
240 mm
